Safety
This unit is intended for indoor use only. Do not operate this unit in direct sunlight, in
contact with fluids, or where there is excessive dust or humidity.
Connect the Back-UPS power cord directly to a wall outlet. Do not use a surge protector or an extension cord.
Connect Equipment
Battery Backup + Surge Protection
Back-UPS
Specifications
Voltage | 120 Vac Nominal | |
Input | Frequency | 60 Hz + 3 |
Brownout Transfers | 92 Vac Typical | |
Over-voltage Transfer | 139 Vac Typical | |
UPS Capacity | BE450G: 450 VA, 257 W; | |
(4 battery backup outlets) | BE550G: 550 VA, 330 W; | |
BE650G1: 650 VA, 390 W | ||
Output | Total Amperage (all outlets) | 12 A (including UPS output) |
Voltage - On Battery | 115 Vac ± 8% | |
Frequency - On Battery | 60 Hz + 1 | |
Transfer Time | 6 ms Typical, 10 ms maximum | |
Protection | AC Surge Protection | Full time, 340 Joules |
and | EMI/RFI Filter | Full time |
Filtering | ||
AC Input | Resettable circuit breaker | |
Type | Sealed, maintenance-free, lead acid | |
BE450G: RBC114 | ||
BE550G: RBC110 | ||
Battery | BE650G1: RBC17 | |
Average Life | 3 - 5 years depending on the number of | |
discharge cycles and environmental | ||
temperature | ||
Net Weight | Replacement battery cartridge | |
BE450G: 10 lb (4.7 kg) | ||
BE550G: 12 lb (5.5 kg) | ||
BE650G1: 14 lb (6.2 kg) | ||
Dimensions | 12 in x 7 in x 3 in | |
Physical | Length x Width x Height | 30 cm x 18 cm x 9 cm |
Operating Temperature | 32º F to 104º F (0º C to 40º C) | |
Storage Temperature | 5º F to 113º F (–15º C to 45º C) | |
Operating Relative Humidity | 0 to 95% non-condensing humidity | |
Operating Elevation | 0 to 10,000 ft (0 to 3000 m) | |
This device complies with part | 68 and part 15 of the FCC rules. | |
EMC | Operation is subject to the following two conditions: (1) This device | |
may not cause harmful interference, and (2) This device must accept any | ||
Compliance | ||
interference received, including interference that may cause undesired | ||
operation. |
Connect the Battery
The Back-UPS is shipped with one battery cable disconnected. Remove the “Stop! Connect the Battery” label that covers the outlets. Prior to connecting any equipment to the unit, connect the battery cable to the unused battery terminal. It is normal for small sparks to be seen when the battery cable is connected to the battery terminal.
bu064a | bu065a |
Press the battery compartment cover | Connect the battery cable securely to the |
release tab located on the rear side of the | |
unit. Slide the battery cover off. | battery terminal. |
bu066a
Reinstall the battery compartment cover. Be sure that the release tab locks into place.
Wall Mount Installation
•Horizontal installation, use 2 screws 7.3' (186.3 mm) apart.
•Vertical installation, use 2 screws 5.4' (137.2 mm) apart.
•Allow 5/16' (8 mm), of the screw to protrude from the wall.
Replace Battery
Use only approved APC replacement battery cartridges.
Deliver used batteries to a battery replacement facility in the packaging provided by APC with the replacement battery cartridge. To order replacement battery cartridges contact APC.
Surge Protection
bu202a
Battery Backup + Surge Protection Outlets
Battery backup outlets provide protection to connected equipment when the Back-UPS is turned on and connected to utility power.
Battery backup outlets receive power from the Back-UPS for a limited period of time when a power outage, or brownout condition occurs.
Battery backup outlets provide protection from power surges or spikes. Connect a computer, monitor and other peripheral devices to the outlets.
Surge Protection Outlets
Surge protection outlets provide protection to connected equipment when the Back-UPS is connected to utility power, and is switched on or off.
Surge protection outlets provide protection from power surges or spikes.
Connect a printer, scanner or other peripheral devices that do not need to remain on during power outages, or utility problems to the surge protection outlets.
Connect Network
Building | Circuit |
Breaker | |
Wiring Fault | |
Network | |
Out | |
Network | Push to |
Reset | |
In | |
PowerChute | bu201a |
USB Port | CAUTION-Refer to bottom |
of unit for safety markings. |
The Back-UPS protects equipment connected to a 10/100 Base-T ethernet, from power surges when connected through the Back-UPS coaxial connectors.
PowerChute® Personal Edition Software
Overview
Use PowerChute Personal Edition software to configure the UPS settings.
Protect your computer and other equipment during a power outage. During a power outage, PowerChute will save any open files on your computer and safely shut it down. When power is restored, it will restart the computer.
Configure the UPS to use features such as power-saving outlets, shutdown configuration, and alarms.
Monitor the UPS for power usage and power events.
Note: PowerChute is only compatible with a Windows operating system. If you are using a Mac OSX, use the native shutdown feature to protect your system. See the documentation provided with your computer.
Installation
Use a USB cable to connect the Data port on the rear panel of the UPS to the USB port on your computer.
If the Back-UPS came with a PowerChute CD, insert the CD into your computer and follow the on-screen instructions
If the Back-UPS did not come with a PowerChute CD, go to www.apc.com and download the software free of charge.
Turn On the Back-UPS
Press the POWER ON button located on the top of the Back-UPS. The Power On/ Replace Battery LED will illuminate and a single short beep will be audible to indicate that the Back-UPS is providing protection for connected equipment.
The Back-UPS battery charges fully during the first 16 hours while connected to utility power. The Back-UPS battery will charge while the Back-UPS is switched on or off and is connected to utility power. Do not expect full battery run capability during the initial charge time.
If the red Building Wiring Fault LED located on the side of the Back-UPS illuminates, do not operate the Back-UPS. Have a qualified electrician correct the building wiring fault.
Warranty
The standard warranty is 3 years in the USA and Canada, 2 years in all other regions from the date of purchase. APC standard procedure is to replace the original unit with a factory reconditioned unit. Customers who must have the original unit back due to assigned asset tags and set depreciation schedules must declare such a need at first contact with APC Technical Support. APC will ship the replacement unit once the defective unit is received by the repair department or cross-ship upon the provision of a valid credit card number. The customer pays for shipping to APC, and APC pays ground freight transportation costs back to the customer.
Status Indicators
Status | LED Indicator | Audible Indicator On | Audible Indicator Terminates |
Power On | The green LED illuminates. | None | N/A |
The Back-UPS is supplying utility power to connected equipment. | |||
On Battery | The green LED illuminates. The LED | Back-UPS beeps 4 | Beeping stops when utility power is restored or |
Back-UPS supplying battery power to battery backup outlets. | is not illuminated during the beeps. | times every 30 seconds. | the Back-UPS is turned off. |
Low Battery warning | The green LED illuminates with rapid | The Back-UPS emits | Beeping stops when utility power is restored or |
The Back-UPS is supplying battery power to the battery backup outlets | rapid beeping, every | ||
and the battery is near a total discharge state. | green flashes. | 1/2 second. | the Back-UPS is turned off. |
Replace Battery | • Replace Battery LED flashes. | Constant tone | |
• The battery is disconnected. | • Replace Battery and Power On | Constant tone | Back-UPS is turned off. |
• The battery needs to be charged, or replaced. | LEDs flash alternately. | ||
Overload Shutdown | |||
While on battery power an overload condition has occurred in one or | None | Constant tone | Back-UPS is turned off. |
more of the battery backup outlets while the Back-UPS is operating on | |||
battery power. | |||
Sleep Mode | The Back-UPS beeps | The beeping stops when: | |
While on battery power the battery is completely discharged. The | • Utility power is restored | ||
None | once every four | ||
Back-UPS will “awaken” once utility power is restored. | |||
• If utility power is not restored within 32 seconds | |||
seconds. | |||
• The Back-UPS is turned off | |||
Building Wiring Fault | Building Wiring Fault LED | None | The Back-UPS is unplugged from the wall outlet |
The building wiring presents a shock hazard that must be corrected by a | illuminates red | or is plugged into an improperly wired outlet. | |
qualified electrical. |
Troubleshooting
Problem and Possible Cause | Solution |
The Back-UPS will not turn on | |
The Back-UPS has not been turned | Press the POWER ON button. |
on. | |
The Back-UPS is not connected to | Make sure the power cord is securely connected to |
utility power, there is no utility power | the wall outlet, and that there is utility power |
available at the wall outlet, or the | available at the wall outlet.Where applicable, |
utility power is experiencing a | check that the wall outlet is switched on. |
brownout or over voltage condition. | |
The battery is not connected. | Connect the battery. Refer to “Connect the |
Battery” on page 1 of this manual. | |
In the event that the Back-UPS receives no utility | |
power and the battery is connected, a cold-start can | |
be initiated. Press and hold the Power On button | |
until the Back-UPS emits two beeps. | |
The Back-UPS is on, the Replace | Battery LED flashes and the unit emits a |
constant tone | |
The battery is disconnected. | Refer to the “Connect the Battery” on page 1. |
Connected equipment loses power | |
A Back-UPS overload condition has | Remove all nonessential equipment connected to |
occurred. | the outlets. One at a time reconnect equipment to |
the Back-UPS. | |
The Back-UPS battery is completely | Connect the Back-UPS to utility power and allow |
discharged. | the battery to recharge for eight hours. |
PowerChute software has performed a | This is normal Back-UPS operation. |
shutdown due to a power failure. | |
Connected equipment does not accept | The output waveform is intended for computers |
the step-approximated sine waveform | and peripheral devices. It is not intended for use |
from the Back-UPS. | with motor driven equipment. |
The Back-UPS may require service. | Contact APC Technical Support for more in depth |
troubleshooting. | |
The Power On LED is illuminated | and the Back-UPS beeps 4 times every 30 |
seconds | |
The Back-UPS is operating on battery | The Back-UPS is operating normally on battery |
power. | power. At this point the user should save all open |
files, and shutdown the computer. When utility | |
power is restored the battery will recharge. | |
The Power On LED flashes once | every second while the Back-UPS beeps once |
every second | |
The Back-UPS battery has | The Back-UPS battery is near a total discharge |
approximately two minutes of | state. At this point the user should save all open |
remaining runtime. | files, and shutdown the computer. When utility |
power is restored the battery will recharge. | |
The Building Wiring Fault LED | illuminates |
The building wiring presents a shock | Do not operate the Back-UPS. Call a qualified |
hazard that must be corrected by a | electrician to correct the building wiring fault. |
qualified electrical. | |
The Back-UPS has an inadequate | battery runtime |
The battery is not fully charged. | Leave the Back-UPS connected to utility power for |
16 hours while the battery charges to full capacity. | |
The battery is near the end of useful | As a battery ages, the runtime capability decreases. |
life and should be replaced. | Contact APC at the Web site www.apc.com, to |
order replacement batteries. | |
The connection from the Back-UPS to the internet is lost during a power | |
outage | |
The modem has lost power. | Connect the modem cable into one of the Battery |
Backup + Surge Protection outlets. |
Voltage Sensitivity Adjustment (optional)
The Back-UPS detects and reacts to line voltage distortions by transferring to battery backup power to protect connected equipment. In situations where either the Back-UPS or the connected equipment is too sensitive for the input voltage level it is necessary to adjust the transfer voltage.
1.Connect the Back-UPS to a wall outlet. The Back-UPS will be in Standby mode, no indicators will be illuminated.
2.Press and hold the ON/OFF button for 10 seconds. The OnLine LED will illuminate alternately green-amber-red, to indicate that the Back-UPS is in
Program mode.
3.The Power On/Replace Battery LED will flash either green, amber, or red to indicate the current sensitivity level. Refer to the table for an explanation of the transfer voltage sensitivity levels.
4.To select LOW sensitivity, press and hold the ON/OFF button until the LED flashes green.
5.To select MEDIUM sensitivity, press and hold the ON/OFF button until the LED flashes red.
6.To select HIGH sensitivity, press and hold the ON/OFF button until the LED flashes amber.
7.To exit Program mode wait five seconds and all LED indicators will extinguish. Program mode is no longer active.
LED | Sensitivity | Input Voltage Range | Recommended Use |
Flashes | Setting | (Utility Operation) | |
Green | LOW | 88 Vac to 142 Vac | Use this setting with equipment that is less |
sensitive to fluctuations in voltage or | |||
waveform distortions. | |||
Red | MEDIUM | 92 Vac to 139 Vac | Factory default setting. Use this setting |
under normal conditions. | |||
Amber | HIGH | 96 Vac to 136 Vac | Use this setting when connected equipment |
is sensitive to voltage and waveform | |||
fluctuations. |
Service
If the unit requires service, do not return it to the dealer. Follow these steps:
1.Review the Troubleshooting section of the manual to eliminate common problems.
2.If the problem persists, contact APC Customer Support.
a.Note the model number and serial number and the date of purchase. The model and serial numbers are located on the rear panel of the unit and are available through the LCD display on select models.
b.Call APC Customer Support and a technician will attempt to solve the problem over the phone. If this is not possible, the technician will issue a Returned Material Authorization Number (RMA#).
c.If the unit is under warranty, the repairs are free.
d.Service procedures and returns may vary internationally. Refer to the APC Web site for country specific instructions.
3.Pack the unit properly to avoid damage in transit. Never use foam beads for packaging. Damage sustained in transit is not covered under warranty. Always
DISCONNECT THE UPS BATTERY before shipping in compliance with U.S. Department of Transportation (DOT) and IATA regulations. The battery may remain in the unit.
4.Write the RMA# provided by Customer Support on the outside of the package.
5.Return the unit by insured, pre-paid carrier to the address provided by Customer Support.
Contact
APC Web site, www.apc.com
© 2011 APC by Schneider Electric. APC, the APC logo, Back-UPS and PowerChute are owned by Schneider Electric Industries S.A.S., American Power Conversion Corporation, or their affiliated companies. All other trademarks are property of their respective owners.
0017
0017
0017
0017
0017
CONNECT TVSS
Back-UPS
®
RS/XS 1200
User’s Manual
1
®
CONTENTS
RJ-45
USB
RJ-11
RJ-11
2
3
CONNECT BATTERY CARTRIDGE
OPERATING ENVIRONMENT
3
4
CONNECT EQUIPMENT / POWER
Monitor
Printer or Scanner
FAX
External Disk or
CD / DVD Drive
Input: 120V~
12A, 60Hz
Circuit Breaker
Push to Reset
SURGE ONLY
BATTERY BACKUP
Computer
5
CHECK BUILDING WIRING
FAULT INDICATOR
Building
Wiring Fault
Wall
Outlet
Modem/
Phone/Fax
TVSS GND
Building Wiring
Fault Indicator
6
Phone Jack
Computer
Modem Port
CONNECT PHONE/MODEM/FAX
TVSS GND
Wall
Outlet
Wall
Outlet
Modem/
Phone/Fax
7
CONNECT 10/100 Base-T or VOIP
Network Jack
Computer
Network Port
8
To Computer USB
Port
CONNECT INTERFACE
Data Port
BR24BP Battery Pack
Computer
11
INSTALL SOFTWARE ON
COMPUTER
There are four status indicators (lights) on the front
panel of the Back-UPS (On Line, On Battery, Overload,
and Replace Battery).
On Line (green)
- is lit whenever utility power is
powering the Battery Backup outlets.
On Battery (yellow)
- is lit whenever the battery of
the Back-UPS is powering equipment connected to the
Battery Backup Outlets.
Four Beeps Every 30 Seconds - this alarm is
sounded whenever the Back-UPS is running On
Battery. Consider saving work in progress.
Overload (red)
- is lit whenever power demand has
exceeded the capacity of the Back-UPS.
Continuous Tone - this alarm is sounded
whenever the Battery Backup outlets are
overloaded.
Circuit Breaker - the circuit breaker button
located on the rear panel of the Back-UPS will
stick out if an overload condition forces the Back-
UPS to disconnect itself from utility power. If the
button sticks out, disconnect non-essential
equipment. Reset the circuit breaker by pushing
the button inward.
Replace Battery (red)
- is lit whenever the battery is
near the end of its useful life, or if the battery is not con-
nected (see above). A battery that is near the end of its use-
ful life has insufficient run-time and should be replaced.
Chirps for 1 Minute Every 5 Hours - this
alarm is sounded whenever the battery has failed
the automatic diagnostic test.
Note: Allow the Back-UPS to charge for a full
eight (8) hours prior to use.
Press the front panel Power ON/OFF switch and
observe that the following events occur after
pressing and releasing the switch:
• The green On Line indicator flashes.
• The yellow On Battery indicator lights while
a Self-Test is being performed.
• When Self-Test has successfully completed,
only the green On Line indicator will be lit.
• If the internal battery cartridge is not
connected (see Step 2 above), the green On
Line indicator and red Replace Battery
indicators will light. The Back-UPS will also
emit a chirping sound.
Continuous Beeping - this alarm is sounded
whenever a low battery condition is reached.
Battery run-time is very low. Promptly save any
work in progress and exit all open applications.
Shutdown the operating system, computer and
the Back-UPS.
If Autoplay is not enabled on the computer, proceed
as follows:
1. On the computer desktop of the display, double-
click on My Computer.
2. Double-click on the CD-ROM drive icon and
follow the on-screen instructions.
If the rear panel Building Wiring Fault (red)
indicator is lit, a potential shock hazard exists
due to one of the following conditions:
• Open or high resistance ground
• Hot or neutral polarity reversed
• Overloaded neutral circuit
Improper building wiring should be
corrected by a qualified electrician. Do not
use the Back-UPS until the condition that
caused the fault is corrected.
Note: Improper building wiring will not
prevent the Back-UPS from operating, but it
will limit its protection capability.
9
SWITCH ON THE BACK-UPS
10
ORIENTATION
12
GROUND
The Back-UPS features a transient
voltage surge-suppression (TVSS)
screw for connecting the ground
lead on additional surge
suppression devices such as
network and data line surge
protectors.
Wall
Outlet
Modem/
Phone/Fax
TVSS GND
From Data Line
TVSS
Follow the
on-screen
instructions.
Apc Back Ups Pro 1500 Manual
On Line
On Battery
Overload
Replace Battery
w
w
w.apc.com
®
RJ-45
USB
10/100 Base-T
VOIP
STATUS INDICATORS AND ALARMS
For connection of APC’s optional
external 24-volt battery pack
(BR24BP) to the Back-UPS RS/XS 1500.
(Back-UPS RS models only)
CABLE
32 - 104
Apc Back Ups 1300 Manual
o
F (0 - 40
o
C)
001b
0017
0017
0017
Back-UPS
®
Apc Back-ups Pro 1400 User Manual 2017
RS/XS 1500
Comments are closed.
